FM TUNER SECTION

• Tuning Range 87.5 – 108.0 MHz

• Mono Usable Sensitivity 9.3 dBf (0.8 µV/75 ohms)

• 50 dB Quieting Sensitivity 13.5 dBf (1.3 µV/75 ohms)

• Alternate Channel Selectivity 80 dB

• Signal-to-Noise Ratio 80 dB

• Stereo Separation 45 Db

AM TUNER SECTION

•  Tuning Range 531 – 1,602 kHz

• Sensitivity (IEC Standard) 22.5 µV/27 dB

                                            CD Player Section

• Frequency Response 5 – 20,000 Hz (±1 dB)

• Wow & Flutter (% WRMS) Below measurable limits

• Dynamic Range 93 dB (at 1 kHz)

• Signal-to-Noise Ratio 105 dB

• Channel Separation 85 dB (at 1 kHz)

                             Tape Player Section

• Tape Speed 1-7/8 ips (4.8 cm/sec)±0.7%

• Wow & Flutter 0.06%WRMS

• Signal-to-Noise Ratio

• With Dolby B-TYPE NR 68 dB

• Without Dolby NR 60 dB

• Frequency Response

• With Alpine Test Tape 30-20,000Hz

                             General Features

• Power Requirement 14.4 V DC

• (11–16 V allowable)

• Power Output 18 W RMS × 4*

• * Primary amplifier ratings per CEA-2006 Standard

• • Power output: measured at 4 Ohms and ≤ 1% THD+N

• • S/N: 80 dBA (reference: 1 W into 4 Ohms)

• Maximum Pre-Output Voltage 2V/10 k ohms

• Weight 2.2 kg (4 lbs. 14 oz)
